Product Overview
STIER Laboratory Glassware Washer H5000D is such a specialized cleaning machine. With a new generation of rear water supply structure, the washer has stronger cleaning power and larger cleaning capacity. It is able to overcome different cleaning challenges and meet the requirements of trace or ultra-trace analysis cleaning. At the same time, it saves a lot of water and consumables, helping the laboratory reduce operating costs. Capable of long-term and stable running without the fuss of frequent maintenance, the washer is a wonderful helper for scientists and researchers.
Capacity
Accommodates 1 - 3 layer frame(s) of washing modules
1-Layer Frame: Graduated Pipettes, Large Volumetric Flasks, Large Blue-Cap Bottles, Large Beakers, etc.
2-Layer Frame: Standard Volumetric Flasks, Blue-Cap Bottles, Beakers, Autosampler Vials, etc.
3-Layer Frame: Petri Dishes, Lids, Scissors, etc.
Product Features
5D Non-Destructive Intelligent Cleaning
Optimized design comprising power, temperature, drying, water quality, and the cleaning solution
Does not damage glassware
Patented Condenser
Avoid venting of vapors into the room
Operates independently of the ventilation system
Residual Heat Drying
Residual temperature drying system
No pollutant precipitation
Eliminates Separate Drying Workflow
Intelligent Water Softener
Softens tap water
Direct use of tap water for cleaning
Save pure water usage
Wide Selection of Basket Racks
Provide the largest variety of rack options
Adaptable to different glassware
Customizable basket racks
Peristaltic Pump
Avoid crystallization of the cleaning solution inside
Neoprene tube, acid and alkali resistant
Applications
Ideal for large and medium laboratories
Product Parameters
| H5000D | |
| External Diameter（mm) | W600*D740*H1330 |
| External Material | Brushed anti-fingerprint stainless steel |
| Inner Chamber Material | 316 Stainless Steel |
| Drying Method | Hot Air Drying |
| Power Supply | 3N AC 380V 50Hz/AC 220V 50Hz |
| Rated Power(kW) | 9/6.5 |
| Heating Power(kW) | 8/5 |
| Water Softener | Standard, Built-in |
| Steam Condenser | Standard, Built-in |
| Detegent Level Sensor | Standard, Built-in |
| Detegent Distrubution Pump | Standard, Built-in |
| Nosie(dBA) | ≤70 |
| Weight(kg) | 120 |
| HEPA Filiter | Optional |
| Conductivity Sensor | Optional |
| More components available for selection | |
